Fiber Cable Pigtails

  • Fiber Cable Pigtails
Fiber Cable Pigtails

Fiber Cable Pigtails

  • Product ID:1024247
  • weight:412.00g
  • Shooting Angle:130
  • Shelf time:2013-12-20 11:07:19
  • Product description: CustomizOffer optical fiber pigtails with various connectors(FC,SC,LC,ST etc),Singlemode/Mulimode Fiber(6/8/12 Multi color Fiber available)ed bath ball
  • INQUIRY   EMAIL


Offer optical fiber pigtails with various connectors(FC,SC,LC,ST etc),Singlemode/Mulimode Fiber(6/8/12 Multi color Fiber available). all are Compliant to Telcordia, EIA/TIA and IEC standards for Factory Terminations.Fiber optic pigtail is an important component commonly used in fiber optic networks. It has fiber connector at one end, and the other is utilised in terminating fiber optic cables via fusion or mechanical splicing. Feature a typical 900um tight buffered as default, it is easy for fusion.

Features

l Low Insertion Loss, Low Return Loss

l Multi Color-Coded

l Easy for On-site Operation

l Tested on optical performance insertion loss and return Loss.

l 900um cable for high density splicing applications.

l Tight buffer for easy fusion or mechanical splicing.

l LC, ST, SC, FC and LSH are available.

l UPC and APC polish type.

l PVC jacket as default, OFNP and LSZH are optional.

Application

l Data Centres, Premise Installations

l Indoor Applications

l ATM, LAN, MAN and WAN

Specification


Parameter

FC,SC,LC

ST,MU,MTRJ

SM

MM

SM

MM

UPC

APC

UPC

UPC

UPC

Insertion Loss(dB)

≤0.2

≤0.2

Return Loss(dB)

≥50

≥60

≥35

≥50

≥35

Repeatability(dB)

△IL≤0.2 △RL≥5

△IL≤0.1

△IL≤0.1

△IL≤0.1

Durability(dB)

△IL≤0.2 △RL≥5

△IL≤0.1

△IL≤0.1

△IL≤0.1

Exchangeability(dB)

△IL≤0.2 △RL≥5

△IL≤0.1

△IL≤0.1

△IL≤0.1

VibrationdB

≤0.2

Fiber Mode

Single Mode: OS2; Multimode: OM1/OM2/OM3/OM4

Cable Diameter(cm)

0.9,2.0,3.0 or specified

Cable Jacket

PVC/LSZH/OFNP/OFNR

Operation Temperature(℃)

-40~75

Storage Temperature(℃)

-45~85
