Features
l Transmission rate: 40Gbps/100Gbps/168Gbps 2.GR-1435 compliant
l Simple structure easy to locate
l Low cost
l Customized products available
Applications
l QSFP quad small form-factor pluggable
l SFP+active optical cables
l Parallel light optical transceiver module
l Communication
l Military applications
l Data centers
l Super computers
MTP&MPOOptical Characteristics
Item |
Parameter |
Reference |
|||
Single mode |
Multi mode |
||||
Standard |
Elite |
Standard |
Elite |
||
Insertion loss |
Typical≤0.30dB Max≤0.75dB |
Typical≤0.15dB Max≤0.35dB |
Typical≤0.50dB Max≤0.25dB |
Typical≤0.10dB Max≤0.35dB |
IEC 61300-3-34 |
Return loss |
≥50dB(UPC) ≥60dB(APC) |
≥55dB(UPC) ≥65dB(APC) |
≥30dB(UPC) |
≥30dB(UPC) |
IEC 61300-3-6 |
