MTP/MPO Patch Cord

  • MPO Patch Panel Specification-3U
MPO Patch Panel Specification-3U

MPO Patch Panel Specification-3U

  • Product description: MPO-LC Type Distribution Box in line with the network development trend of high density high capacity, MPO interface of multi-channel signal switching to LC type interface, the module box encapsulatio
  • INQUIRY   EMAIL

Features

l   Suitable for 19 inch standard frame.

l   Suitable for ribbon and single fiber.

l   Compact design for space saving.

l   Front mark on the plate is easy for identification and operation.

l   Standard size, light weight and reasonable structure.

l   Easy for management and operation.

l   Modular design, which can be used in multiple module boxes and configured in MPO-LC Type Distribution Box.

l   The MPO ribbon multi-core fiber is divided into multiple lc interfaces to realize parallel conversion of MPO-LC.

Applications

l   Telecommunications subscriber loop

l   Fiber to the home (FTTH)

l   LAN/WAN

l   CATV

Mechanical and environmental characteristics

Projects

Parameter

Operating temperature

-25℃~+40℃

Storage temperature

-25℃~+55℃

Relative humidity

≤85(+30℃)

Air pressure

70Kpa~106Kpa

Color

Black

Specifications and Models

Model

MPO-LC Type Cassette Quantity

Height

Dimension(LxWxH)

MPO-LC

9

3U

482mmx250mmx133.5mm
