Features
l Standard size, light weight and reasonable structure.
l Compact design for space saving.
l Front mark on the plate is easy for identification and operation.
l Easy for management and operation.
l Supports 40G and 100G network applications .
l High reliability.
l Excellent environmental stability.
Applications
l Telecommunications subscriber loop
l Fiber to the home (FTTH)
l LAN/WAN
l CATV
l Other applications in fiber optic systems.
Mechanical and environmental characteristics
|
Projects |
Parameter |
|
Operating temperature |
-25℃~+70℃ |
|
Storage temperature |
-25℃~+70℃ |
|
Relative humidity |
≤85％(+30℃) |
|
Color |
Black |
|
Max. Capacity |
24 port (LC) |
|
Dimension(LxWxH) |
155 mm x 95mm x35mm |
|
Performance Level |
Standard |
Elite |
|||
|
Connector |
cable |
IL(max) |
RL |
IL(max) |
RL(max) |
|
MPO/MTP |
OM4 |
≤0.70dB |
≤20dB |
≤0.35dB |
≤20dB |
|
LC |
≤0.20dB |
≤30dB |
≤0.10dB |
≤30dB |
|
