MTP/MPO Patch Cord

  • MPO&MTP Cassette Specification-12
MPO&MTP Cassette Specification-12

MPO&MTP Cassette Specification-12

  • Product description: MPO&MTP Cassettes are designed for Data Center Solutions supporting the to pologies as specified in the Data Center Standards EN50173-5 and ISO/IEC24764. MPO&MTP cassettes connected with MPO Trunk or
  • INQUIRY   EMAIL

Features

l   Standard size, light weight and reasonable structure.

l   Compact design for space saving.

l   Front mark on the plate is easy for identification and operation.

l   Easy for management and operation.

l   Supports 40G and 100G network applications .

l   High reliability.

l   Excellent environmental stability.

Applications

l   Telecommunications subscriber loop

l   Fiber to the home (FTTH)

l   LAN/WAN

l   CATV

l   Other applictaions in fiber optic systems.

Mechanical and environmental characteristics

Projects

Parameter

Operating temperature

-25℃~+70℃

Storage temperature

-25℃~+70℃

Relative humidity

≤85(+30℃)

Color

Black

Max. Capacity

12 or 24 port (LC)

Dimension(LxWxH)

116mmx 101mmx36.5mm

Environmental Properties

Performance Level

Standard

Elite

Connector

cable

IL(max)

RL

IL(max)

RL(max)

MPO/MTP

OM4

0.70dB

20dB

0.35dB

20dB

LC

0.20dB

30dB

0.10dB

30dB
