DCI-WDM system

  •  2* 400G CFP2 Muxponder 400G CFP2 MUXPONDER, OTU 2X400G TRANSPONDER
 2* 400G CFP2 Muxponder 400G CFP2 MUXPONDER, OTU 2X400G TRANSPONDER

 2* 400G CFP2 Muxponder 400G CFP2 MUXPONDER, OTU 2X400G TRANSPONDER

  • Maximum capacity:8x100G
  • Wavelength :DWDM: 1529.16nm-1567.14nm
  • Service access types: 100GE, OTU4.
  • Working temperature:-10℃ ~ 70℃
  • Product description: The 2* 400G CFP2 muxponder provides a high-quality solution for solving transmission lines with insufficient fiber resources and high fiber line loss.
  • INQUIRY   EMAIL

Product Overview

The 2* 400G CFP2 muxponder is a 8*100G service access module designed and developed by Anycoms for optical fiber links. It can realize the wavelength tunable of CFP2 coherent optical module and can be converted into DWDM standard wavelength optical signal. Interconnection with DWDM multiplexer/demultiplexer to realize wavelength division multiplexing transmission. It provides a high-quality solution for solving transmission lines with insufficient fiber resources and high fiber line loss.



Features

lSupport DWDM transmission, wavelength conversion.

lThe single card supports 8 channels 100G unidirectional or bidirectional service access.

lThe line side supports 2 channels 400G CFP2 coherent optical modules access.

lSupporting multiple client-side service access: 100G Base-SR4/CWDM4/LR4/PSM4.



Specifications

System Parameter

2* 400G CFP2

Maximum capacity

8100G bidirectional transmission    8*100G unidirectional transmission

Wavelength (frequency) range

DWDM: 1529.16nm-1567.14nm(191.3THz-196.05THz)

Modulation

DP-QPSK@100G 50Ghz, DP-16QAM@200G 50Ghz, DP-16QAMps@200G 50Ghz, DP-QPSK@200G 75Ghz, DP-16QAM@400G 75Ghz.

OSNR tolerance

<12dB@100G QPSK, <20.5dB@200G DP-16QAM <16dB@200G DP-16QAMps, <13.5dB@200G DP-QPSK, <22dB@400G DP-16QAM.

Service access types

100GE, OTU4.

Dispersion tolerance

±40000ps/nm@100G

OSNR tolerance

<12.5dB@100G

Dimensions (mm)

177(W)*40(H)*225(D)

Working temperature

-10℃ ~ 70℃

Storage temperature

-40℃ ~ 80℃

Relative humidity

5% ~ 95% no condensation

Safety and EMC

Compliance with FCC, UL, CE, TUV, CSA standards.

Power consumption

<90W
