DCI-WDM system

200G CFP2 MUXPONDER, OTU 2X200G TRANSPONDER

Maximum capacity：4x100G
Wavelength :DWDM: 1529.16nm-1567.14nm
Service access types: 100GE, OTU4.
Working temperature:-10℃ ~ 70℃
Product description: The single cardsupports 4 channels 100G unidirectional or bidirectional service access. The line side supports 2 channels 200G CFP2coherent optical modules，Support multiple client-side service access
INQUIRY EMAIL

Product Overview

The 2*200G CFP2 muxponder is a 4*100G service access module designed and developed by Anycoms for optical fiber links. It can realize the wavelength tunable of CFP2 coherent optical module and can be converted into DWDM standard wavelength optical signal. Interconnection with DWDM multiplexer/demultiplexer to realize wavelength division multiplexing transmission. It provides a high-quality solution for solving transmission lines with insufficient fiber resources and high fiber line loss.

Features

lSupporting DWDM transmission, wavelength conversion.

lThe single card supports 4 channels 100G unidirectional or bidirectional service access.

lThe line side supports 2 channels 200G CFP2 coherent optical modules access.

lSupport multiple client-side service access: 100G Base-SR4/CWDM4/LR4/PSM4.

Specifications

System Parameter	2*200G CFP2
Maximum capacity	4100G bidirectional transmission 4100G unidirectional transmission
Wavelength (frequency) range	DWDM: 1529.16nm-1567.14nm(191.3THz-196.05THz)
Modulation	DP-QPSK@100G, DP-16QAM@200G, DP-16QAMps@200G, DP-QPSK@200G.
Service access types	100GE, OTU4.
Dispersion tolerance	±40000ps/nm@100G
OSNR tolerance	<12dB@100G QPSK, <21dB@200G DP-16QAM, <16dB@200G DP-16QAMps, <13.5dB@200G DP-QPSK.
Dimensions (mm)	177(W)40(H)225(D)
Working temperature	-10℃ ~ 70℃
Storage temperature	-40℃ ~ 80℃
Relative humidity	5% ~ 95% no condensation
Safety and EMC	Compliance with FCC, UL, CE, TUV, CSA standards.
Power consumption	<78W
