DWDM Mux/Demux

  • 100GHz 200GHz DWDM Module in LGX Box
100GHz 200GHz DWDM Module in LGX Box

100GHz 200GHz DWDM Module in LGX Box

  • Channel Spacing: 100GHz/200GHz
  • Number of Channels: 4,8 Channel
  • In/Out Connector: Customized
  • Multi-Number of Channels: Customized
  • Product description: Anycoms 100GHz/200GHz wavelength multiplexer(100,200G DWDM OADM Module) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging to achieve optical
  • INQUIRY   EMAIL

Anycoms 100GHz/200GHz wavelength multiplexer(100,200G DWDM OADM Module) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging to achieve optical add or drop at a ITU wavelength. It provides ITU channel center wavelength, low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path . It can be used for wavelength add/drop in telecommunication network system.

Features

l Low Insertion Loss

l Wide pass band

l High channel

l High stability and reliability

l Epoxy free on optical path

Applications

l Channel Add/Drop

l DWDM network

l Wavelength Routing

l CATV fiber optic System

l Fiber optical amplifier

Performance Specifications

Parameter

4 Channel

8 Channel

Mux

Demux

Mux

Demux

Channel Wavelength(nm)

ITU Grid

Channel Spacing(GHz)

100/200

Channel Passband (@-0.5dB bandwidth)(nm)

>0.3(100G)/ >0.5(200G)

Insertion Loss(dB)

1.8

3.0

Channel Uniformity (dB)

0.6

1.0

Channel Ripple(dB)

<0.3

Isolation(dB)

Adjacent

N/A

>30

N/A

>30

Non-adjacent

N/A

>40

N/A

>40

Insertion Loss Temperature Sensitivity(dB/)

<0.005

Wavelength Temperature Shifting(nm/)

<0.002

Polarization Dependent Loss(dB)

<0.1

Polarization Mode Dispersion(ps)

<0.1

Directivity(dB)

>50

Return Loss(dB)

>45

Maximum Power Handling(mW)

300

Operating Temperature()

-5~+75

Storage Temperature()

-40~+85

Package dimension(mm)

L155.5×W102(129)×H29 or Specify

1, Above specifications are for devices without connector.

2, Specifications may change without notice.
